Product Introduction

MGM's Super Flexible Spacer is an advanced warm-edge solution engineered specifically for the manufacturing of curved, arched, and irregularly shaped insulating glass units (IGUs). Unlike rigid aluminum or stainless steel spacers that are impossible to bend into smooth, small-radius curves, our spacer boasts exceptional malleability, allowing it to be effortlessly formed by hand, or with simple tools, or automatically applied on an insulating glass production line, to match the exact contour of the glass.

This spacer is a composite material, its sophisticated construction delivers multiple performance benefits: Superior Thermal Efficiency: It drastically reduces heat transfer at the glass perimeter, leading to higher overall U-values, elimination of cold spots, and prevention of condensation. Enhanced Durability: The robust, non-corrosive materials ensure the long-term structural integrity of the IGU, even under significant thermal stress and movement. Simplified Production: It eliminates the need for complex mechanical corner keys and tedious manual assembly of rigid spacers for curved glass, streamlining your production process for both standard and custom shapes. By using MGM's Super Flexible Spacer, you can expand your product portfolio to include high-value curved IGUs for architectural domes, automotive glass, and designer windows, meeting the growing market demand for both aesthetic freedom and top-tier energy performance.


Technical Data
Type Rectangular Strips T-shaped Strips (Without Butyl Rubber) T-shaped Strips (With Butyl Rubber)
Finished Chemical Product Silicone with Molecular Sieve
Colour Customizable
Density 0.95g/cm3
Dew Point Not higher than -40°C (Can reach -70°C in actual tests)
Size 6-29mm
Limination Method Manual or Mechanical

Performance

Compatible with oversized curtain wall IG units

Silicone polymer structure provides ozone resistance, UV stability and oxidation resistance

Elasticity maintained in high temperature range, no misalignment in multi-chamber IG units

Support colour customization

Accommodates curved and/or shaped glass

Monolithic extrusion technology ensures optically smooth and defect-free surface

High molecular sieve retention ensures no particle shedding

Premium argon gas retention performance, multi-layer barrier film reduces moisture vapor transmission and prevents chemical fogging
